Universal PC Board YY-U10A for Floor Standing Split Air Conditioners

Description

The Universal PC Board YY-U10A is a reliable control system designed specifically for non-inverter floor standing split air conditioners. Featuring broad multi-brand compatibility, this versatile AC replacement board serves as an ideal replacement for faulty or burnt PCBs in high-capacity standing units. Built with industrial-grade electronic components, the YY-U10A delivers stable electrical performance, accurate temperature regulation, and long-term operating reliability for residential and commercial HVAC maintenance projects.

Technical Specifications

Key Features

• Universal Model Compatibility: Fits a wide range of non-inverter floor standing split AC units across leading brands.

• Compressor Protection: Built-in relay output with safety time-delay and overload protection to prevent compressor damage.

• Multi-Speed Indoor Blower Control: Offers 3 adjustable fan speeds (Low, Medium, High) for customized airflow.

• Outdoor Fan Relay: Dedicated output relay ensures optimal outdoor condenser fan operation.

• Precision Sensors: High-accuracy temperature sensor inputs deliver balanced room temperature regulation.

• Circuit Safety: Integrated overload, overheat, and short-circuit protection for stable voltage management.

• Technician-Friendly Layout: Clear, labeled wiring connections allow for easy installation.

• Durable Components: Industrial-grade PCB materials built to withstand high operating temperatures.

System Compatibility

• Compatible AC Types: Standard Non-Inverter Floor Standing Split Air Conditioners.

• Compatible Fan Motors: 3-speed indoor blower motors and standard outdoor condenser fan motors.

• Brand Compatibility: Universal application across major non-inverter standing AC brands (such as LG, Gree, Midea, TCL, Samsung, and others).

Applications & Functions

• Standing Unit Repairs: Fast repair and replacement of burnt or short-circuited PCBs in floor standing split ACs.

• Operating Modes: Supports Cooling, Heat Pump Heating, Auto, Sleep, and Fan-Only operations.

• Timer Functions: Programmable Timer ON/OFF for customized operating schedules.

• Self-Diagnostic Safety: Automated error detection prevents system overheating and voltage damage.

Installation & Technician Notes

• Professional Installation Required: Installation must be performed by a qualified HVAC technician.

• Pre-Purchase Verification: Ensure the target system is a non-inverter floor standing split air conditioner prior to ordering.

• Wiring Setup: Features clearly labeled terminal connections; refer to the included installation manual and schematic diagram for accurate setup.

Package Includes

• 1 x Main Control PCB (YY-U10A)

• 1 x Multi-Function Wireless Remote Control

• 1 x Temperature Sensor Harness (Room & Pipe Sensors)

• 1 x Complete Wiring Harness

• 1 x Installation Manual & Wiring Diagram

Important Buyer Verification Notes

Notice for Buyers & Technicians: Before ordering, confirm that your air conditioner is a standard non-inverter floor standing split unit. Verify that terminal layouts and control relay requirements align with universal installation standards.

Why Buy From Al Ramiz

• Genuine Quality Parts: Dependable, factory-tested HVAC spare parts and control boards.

• UAE Stock & Local Inventory: Fast processing and local dispatch across the UAE.

• Technical Product Support: Assistance with component selection and product verification.

• Competitive Pricing: Cost-effective solutions for contractors and service technicians.

Frequently Asked Questions (FAQs)

Is the Universal PC Board YY-U10A compatible with floor standing split AC units?

Yes, it is designed specifically to work with non-inverter floor standing split air conditioners as well as conventional split systems.

Is the Universal PC Board YY-U10A compatible with all standing AC brands?

Yes, it works universally with non-inverter standing split ACs from LG, Gree, Midea, TCL, Samsung, and other major brands.

Can I use the YY-U10A board for inverter air conditioners?

No, this control board is strictly designed for non-inverter split air conditioners only.

What protective features are built into the YY-U10A control board?

It features built-in compressor time-delay and overload protection, along with integrated overheat and short-circuit safeguards.

How many fan speeds can be controlled using this board?

It offers 3 adjustable indoor fan speeds supporting Low, Medium, and High settings.
