Thermostat Honeywell T6861
The Honeywell T6861 is a premium digital thermostat designed for use with fan coil units in residential, commercial, and hospitality environments. Known for its precision, reliability, and ease of use, this thermostat supports both 2-pipe and 4-pipe HVAC systems. Its large, backlit LCD display provides clear visibility and simple navigation, making it a preferred choice for modern temperature control needs.
This thermostat offers both automatic and manual fan speed control, with the flexibility to program energy-saving features, such as scheduled on/off functions and occupancy-based settings via external contacts. With user settings retention and freeze protection, the T6861 ensures consistent and safe operation in any environment.
Applications
-
Fan coil units in hotels and hospitality suites
-
Residential heating and cooling systems
-
Office buildings and commercial complexes
-
Multi-unit apartments and condominiums
Features
-
Large LCD screen with temperature and status display
-
Compatible with 2-pipe and 4-pipe fan coil systems
-
Manual or automatic 3-speed fan control
-
Built-in sensor with optional remote sensor capability
-
Adjustable temperature range from 10°C to 32°C
-
Power supply: 110V or 220V AC
-
Time on/off programming for energy efficiency
-
Freezing protection function to avoid low-temperature damage
-
Retains user settings after power loss
-
Selectable temperature units (°C/°F)
Typical Specifications
Parameter | Specification |
---|---|
Model | Honeywell T6861 |
Power Supply | 110/220 VAC |
Control Type | On/Off valve and fan control |
Fan Speed | 3-speed (Auto/Manual) |
Display | Large LCD with backlight |
Mounting | Standard 86×86 mm box (horizontal/vertical) |
Temperature Range | 10°C to 32°C (adjustable) |
Sensor Type | Built-in NTC; remote sensor optional |
Pipe Compatibility | 2-pipe and 4-pipe systems |
Frequently Asked Questions
Q1: Is the Honeywell T6861 thermostat suitable for hotel rooms?
Yes, the T6861 is widely used in hotel and hospitality settings due to its sleek design, energy-saving features, and reliable performance.
Q2: Can it be used in a 4-pipe HVAC system?
Yes, the thermostat supports both 2-pipe and 4-pipe systems, making it highly versatile for different HVAC configurations.
