Description
Soldering Filter Drier EK-165S 1/4″
The EK-165S is a high-quality solder-type liquid line filter drier designed to protect refrigeration and air conditioning systems from moisture, acids, and solid contaminants. Manufactured with a solid core desiccant and a 20-micron filtration pad, this filter drier ensures effective removal of harmful particles and water vapor, which helps maintain system efficiency and prolong equipment life.
The solder connection type allows for a secure and leak-proof installation, making it ideal for both new system assemblies and service replacements in HVAC and refrigeration units.
Applications
-
Residential, commercial, and industrial HVAC systems
-
Refrigeration systems including supermarkets, cold storage, and transport refrigeration
-
Suitable for use with CFC, HCFC, and HFC refrigerants such as R-22, R-134a, R-404A, and more
-
Heat pumps and split system air conditioners
-
Recommended for installation during compressor replacements, major repairs, or system retrofits
Key Features
-
Solid Core Desiccant: Utilizes high-quality molecular sieve desiccant for superior moisture and acid absorption capacity.
-
20-Micron Filtration: Captures solid contaminants and particles to protect system components and reduce wear.
-
Solder Connection: Provides a reliable, permanent joint ensuring no leakage and easy integration with copper piping.
-
Wide Refrigerant Compatibility: Approved for use with a broad range of refrigerants and compatible with POE oils used in modern HVAC systems.
-
Corrosion-Resistant Steel Shell: Durable construction with an epoxy powder coat finish resists corrosion and mechanical damage during installation and operation.
-
High Pressure Rating: Rated to withstand pressures up to 680 psig (46.9 bar), suitable for most residential and commercial systems.
Specifications
| Parameter | Details |
|---|---|
| Model | EK-165S |
| Connection Type | 1/4″ Solder |
| Desiccant Volume | Solid core with molecular sieve |
| Filtration Level | 20 microns |
| Max Working Pressure | 680 psig (46.9 bar) |
| Refrigerant Compatibility | CFC, HCFC, HFC refrigerants (e.g., R-22, R-134a, R-404A) |
| Oil Compatibility | POE oils |
| Shell Material | Steel with epoxy powder coating |
| Operating Temperature Range | -40°C to +70°C |
Frequently Asked Questions
Q1: Is the EK-165S suitable for use with R-410A refrigerant?
Q2: How often should the filter drier be replaced?
