Description
The XLP Sheet Roll ALU/ADH is a premium thermal and acoustic insulation solution designed for HVAC, refrigeration, and construction applications. Made from cross-linked polyethylene (XLP), this roll provides excellent heat insulation, vibration damping, and moisture resistance.
The sheet is laminated with a high-quality aluminum foil on one side, which acts as a radiant heat barrier and enhances fire resistance. On the other side, it comes with a strong self-adhesive backing, ensuring quick, clean, and secure installation without the need for additional adhesives or fasteners.
XLP insulation is lightweight, flexible, and durable, making it suitable for wrapping ducts, pipes, walls, and roofing. It not only reduces energy loss but also prevents condensation and dampness, extending system life and improving overall efficiency.
Key Features
-
✅ Cross-Linked Polyethylene Material – lightweight, flexible, and long-lasting.
-
✅ Aluminum Foil Lamination – enhances thermal resistance and reflects radiant heat.
-
✅ Self-Adhesive Backing – easy, quick, and secure installation.
-
✅ Moisture & Vapor Barrier – prevents condensation and dampness.
-
✅ Thermal & Acoustic Insulation – reduces heat loss, noise, and vibration.
-
✅ Wide Application Range – HVAC ducts, pipes, roofing, and wall insulation.
Specifications (Typical Values – customizable by supplier)
| Property | Value |
|---|---|
| Material | Cross-linked Polyethylene (XLP) |
| Surface Finish | Aluminum Foil Lamination |
| Backing | Self-Adhesive (ADH) |
| Thickness Range | 3 mm – 25 mm |
| Roll Width | 1.0 m – 1.2 m |
| Thermal Conductivity | ~0.034 W/m·K |
| Water Absorption | <0.1% |
| Fire Resistance | Class 0 / Class 1 (as per standards) |
Applications
-
HVAC Duct Insulation – reduces heat gain/loss in air-conditioning ducts.
-
Refrigeration & Cold Storage – prevents condensation and energy loss.
-
Building Insulation – walls, ceilings, and roofing thermal protection.
-
Pipe Wrapping – hot and cold water pipelines, chilled water systems.
-
Industrial Equipment – vibration and noise dampening.
Usage Guidelines
-
Ensure surfaces are clean and dry before applying.
-
Peel and press the adhesive side firmly for secure bonding.
-
Use protective gear during installation in high-temperature areas.
-
Do not expose directly to open flame.
FAQs
Q1: What does ALU/ADH mean in XLP Sheet Roll?
A: ALU refers to aluminum foil lamination, and ADH refers to the adhesive backing for easy installation.
Q2: Is this insulation suitable for outdoor use?
A: Yes, but it should be protected with cladding or UV-resistant coating if exposed to direct sunlight.
Q3: Can it be used in both hot and cold applications?
A: Yes, it is effective for hot water pipes, chilled water lines, and HVAC ducts.
Q4: Does it reduce noise as well?
A: Yes, the cross-linked polyethylene structure helps with acoustic insulation and vibration damping.
