Description
The Emerson EK-164S Filter Drier is a premium liquid line filter drier designed for use in refrigeration and air conditioning systems. With a 1/2-inch solder (sweat) connection, it effectively removes moisture, acids, and solid contaminants, ensuring optimal system performance and longevity.
Applications
-
Commercial and residential refrigeration systems
-
Air conditioning units, including split and central systems
-
Heat pump systems
-
Food service refrigeration equipment.
Features
-
Desiccant Blend: 75% molecular sieve and 25% activated alumina for high moisture and acid removal capacity
-
Filtration: 20-micron outlet pad ensures effective contaminant removal
-
Construction: Solid copper connections with a corrosion-resistant epoxy powder paint finish
-
Compatibility: Suitable for CFC, HCFC, and HFC refrigerants, including R-12, R-134a, R-22, R-404A, R-407C, R-410A, R-500, R-502, and R-507
-
Approval: UL/CUL listed (File No. SA3124) and approved for use with POE oils in Copeland™ compressors
-
Durability: Shock-resistant steel shell construction for enhanced reliability.
Specifications
| Attribute | Details |
|---|---|
| Model | EK-164S |
| Connection Type | 1/2″ ODF Solder (Sweat) |
| Unit Size | 16 cubic inches |
| Filtration Level | 20 microns |
| Desiccant Blend | 75% molecular sieve / 25% activated alumina |
| Maximum Working Pressure | 680 psig (4688 kPa) |
| Refrigerant Compatibility | R-12, R-134a, R-22, R-404A, R-407C, R-410A, R-500, R-502, R-507 |
| Operating Temperature Range | -30°C to +80°C |
| Approvals | UL/CUL File No. SA3124 |
| Finish | Epoxy powder paint |
| Shell Material | Steel |
| Length | 6.33 inches (approx. 161 mm) |
| Weight | Approximately 1.35 lbs (0.61 kg) |
Questions
-
Which refrigerant is your system currently using to ensure compatibility with the EK-164S filter drier?
-
Are you replacing an existing filter drier or installing a new one in your refrigeration or air conditioning system?
