Description
Filter Drier Flaring EK 032F
The EK 032F is a high-efficiency filter drier with flaring connection, designed specifically for refrigeration and air conditioning systems. It plays a vital role in ensuring system reliability by removing moisture, acid, and solid particles from refrigerants and oils. With a compact design and proven filtering performance, the EK 032F is ideal for both residential and commercial HVAC systems.
Applications
-
Refrigeration and air conditioning systems using CFC, HCFC, and HFC refrigerants
-
Domestic and light commercial units
-
Heat pump systems
-
After component replacements or major repairs
-
Ideal for use in service and OEM applications
Key Features
-
Solid core with high moisture and acid absorption capacity
-
Flaring connection for easy installation and replacement
-
Compact and robust design for space-constrained systems
-
Low pressure drop ensures energy-efficient operation
-
Compatible with a wide range of refrigerants and oils
-
Corrosion-resistant coating for extended service life
Specifications
| Parameter | Details |
|---|---|
| Model | EK 032F |
| Connection Type | Flaring |
| Connection Size | 1/4 inch |
| Refrigerant Compatibility | CFC, HCFC, HFC (R22, R134a, R404A, etc.) |
| Filtration | 20 microns |
| Desiccant Type | 100% Molecular Sieve |
| Moisture Removal | High Capacity |
| Pressure Drop | Low |
| Max Operating Pressure | 46 bar (667 psi) |
| Flow Direction | Bi-directional |
| Temperature Range | -40°C to +70°C |
Frequently Asked Questions
Q1: Can the EK 032F be used with R410A refrigerant?
A1: No, the EK 032F is not recommended for R410A systems due to pressure limitations. Consider using a high-pressure-rated drier for R410A.
Q2: How often should the filter drier be replaced?
A2: It’s best to replace the filter drier whenever the refrigeration system is opened for service, such as during compressor replacement or after a leak repair.
